Strataflo Brass Foot Valves With Stainless Steel Strainer
Strataflo Brass Foot Valve 3/4" # 200-075
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Strataflo Brass Foot Valve 3/4" # 200-075
One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: Female NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: 225 degrees F. Overall length: 3-3/4" (Fits inside 1-1/4" pipe) Weight: 1/2 lbs.
Strataflo Brass Foot Valve 1" # 200-100
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Strataflo Brass Foot Valve 3/4" # 200-075
One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: 1" Female NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: 225 degrees F. Overall length: 4-3/8" (Fits inside 2" pipe) Weight: 5/8 lbs.
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Construction: One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: Female NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: 225 degrees F. Overall length: 4-1/16" (Fits inside 2" pipe) Enters pipe size: 2" Weight: 3/4 lbs.
Strataflo Brass Foot Valve 1-1/2" # 200-150
Strataflo Brass Foot Valve 1-1/2" # 200-150
Strataflo Brass Foot Valve 1-1/4" # F200A-125
Construction: One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: Female NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: 225 degrees F. Overall length: 5-9/16" (Fits inside 3" pipe) Weight: 1.5 lbs.
Strataflo Brass Foot Valve 2" # 200-200
Strataflo Brass Foot Valve 1-1/2" # 200-150
Strataflo Brass Foot Valve 2" # 200-200
Construction: One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: Female NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: 225 degrees F. Overall length: 5-3/8" (Fits inside 3-1/2" pipe) Weight: 3 lbs.
Strataflo Brass Foot Valve 3" # 200-300
Strataflo Brass Foot Valve 1-1/2" # 200-150
Strataflo Brass Foot Valve 2" # 200-200
One piece cast brass body, silicone treated metal reinforced Buna-S tapered rubber poppet, stainless steel spring wire strainer. Connections: 3" Male NPT (National Pipe Thread) Working pressure: Up to 400 PSI Maximum temperature: Up to 225 degrees Fahrenheit Overall length: 6-3/8" (Fits inside 4" pipe) Weight: 6.5 lbs.
